Product name:4G AOV Intelliaent PTZ Camera
Model：STCA-04B
Packing Information
Giftbox Size:mm
Carton Size:mm
- Connection and Size Picture
- Specification
- Accessories
-
Feature:
1、AOV (always-on-video) technology, 24-hours full day recording
2、2MP+2MP+2MP+2MP pixel 4 lens, H.265
3、Support 4G SIM card, two-way voice intercom, voice alarm, picture push
4、13W solar panel+16000mah battery
5、Full color night vision,Human motion tracking
6、PTZ Rotation:Pan 355⁰/ Tilt 90⁰
7、White lights+ IR lights, with bracket and antenna
-
Product
Modle
STCA-04B
system
CPU
1.0T computing power high-performance dual-core CPU
OS
Embedded Linux operating system
lens
focal length
4mm+4mm+4mm+8mm
aperture
F1.4+F1.4+F1.4+F1.4
video
sensor
Four way 1/3’ CMOS Sensor
coding
H.265+
format
PAL 50HZ/NTSC 60HZ
pixel
1920*1080（2MP+2MP+2MP+2MP）
frame rate
10fps
bitstream
135kbps-2048kbps
Day/Night Mode
Black and white, full-color, intelligent, starlight
Capture
support
audio
coding
G.711U
Input
Built in passive MIC
Output
Built in 8R2W speaker
Voice call
Full duplex voice call
recording
method
AOV recording, alarm recording
storage
TF card/cloud recording（domestically）
alarm
AI detection
Accurate humanoid AI function（40M）
trigger
Humanoid detection alarm
voice
Multiple voice options
linkage
Recording and capturing
Pan-Tilt
preset position
Support 6 preset position settings
Tracking
Support precise humanoid tracking
network
4G
Full network 4G (overseas version supports 4G cloud card)
Solar and batteries
Solar panels
5V 13W and above
batteries
8*2000mAh 18650 battery
Charge
Support three-stage intelligent charging (trickle, constant current, constant voltage) and low voltage over discharge protection
other
capacity
Maximum support for 256 GB (universal FAT32 format)
Woeking Voltage
DC5V~9V power supply （TYPE-C）（maximum support 9V 3A）
Operating Temperature
-20℃~55℃
